Recommended feed rate for different Materials
Recommended feed rate for CNC router wood machinery listed in table below
| Material | Feedrate | Plunge Rate | Direction | Tool Dia. |
|---|---|---|---|---|
| 3mm Acrylic | 3000mm/min | 1200mm/min | climb | 3.175mm |
| 4.5mm Acrylic | 2500mm/min | 1200mm/min | climb | 3.175mm |
| 6mm Acrylic | 2500mm/min | 1200mm/min | climb | 4.76mm |
| 10mm Acrylic | 2000mm/min | 1000mm/min | climb | 6.35mm |
| 20mm Acrylic | 1500mm/min | 800mm/min | climb | 6.35mm/8mm |
| 3mm Aluminium | 2500mm/min | 400mm/min | Conventional | 3.175mm |
| 6mm Aluminium | 1800mm/min | 300mm/min | Conventional | 4.76mm |
| 10mm Aluminium | 1500mm/min | 200mm/min | Conventional | 6.35mm |
| 10mm MDF | 12000mm/min | 1200m/min | Conventional | 4.76mm |
| 16mm MDF | 12000mm/min | Ramp Plunge | Conventional | 12.70mm |
| 16mm whiteboard | 12000mm/min | Ramp Plunge | Conventional | 12.70mm |
| 20mm MDF | 8000mm/min | 800mm/min | Conventional | 8/12mm |
| 10mm Plywood | 8000mm/min | 1200mm/min | Conventional | 4.76mm |
| 16mm Plywood | 7000mm/min | 1200mm/min | Conventional | 6.35mm |
| 25mm Plywood | 6000mm/min | 800mm/min | Conventional | 8/12mm |
| 12mm Hardwood | 6000mm/min | 1000mm/min | Conventional | 6.35mm |
| 19mm Hardwood | 4000mm/min | 800mm/min | Conventional | 6/8mm |
| 35mm Hardwood | 2000mm/min | 700mm/min | Conventional | 12/16mm |
